Spectrum Analyzer USB LTDZ 35-4400M Spectrum Signal Source with Tracking Source Module RF Frequency Domain Analysis Tool

Save $27
CartoolshopSKU: Spectrum Signal Source

$57.99 $84.99

Tax included Shipping calculated at checkout

In stock


Update information: There will be some differences in appearance, and the functions and usage methods are consistent with the old version.
Attribute: RF frequency domain analysis tool

    Interface: usb
    Power supply: usb
    Standby current: ≤100mA
    Sweep current: ≤350mA
    Sweep bandwidth: 33mHz---4400mHz
    Turn on the tracking source output bandwidth 33mhz---3000mhz
    Sweep step: ≥ 33~68.75mHz/125Hz, 68.75~137.5mHz/250Hz, 137.5~275mHz/500Hz, 275~550mHz/1kHz
                              550~1100mHz/2kHz, 1100~2200mHz/4kHz, 2200~4400mHz/8kHz,
    Sweep speed: ≥800 points / sec
    Sweep dynamic log ratio: > 50dB
    Point frequency or sweep output power: ≈0 dBm
    Input detection: ≤10dbm
    Background: ≈ -60dBm
    Software used on the computer side: NWT4.11.09 version
    Computer operating system: winxp, win7, win10

    Package includes:
    1 x Spectrum Analyzer
    The appearance has undergone some changes, and the functions remain the same. Please pay attention before buying:
