New P210 70M-6GHz SDR Software Define Radios AD9361 ZYNQ7020 Pluto SDR Openwifi
New P210 70M-6GHz SDR Software Define Radios AD9361 ZYNQ7020 Pluto SDR Openwifi
In stock
-
All orders are dispatched the next 3 business days!
-
We will beat any price. We back all products with a 1 year guarantee.
Order in the next 0 hours 0 minutes to get it by /06/2026
Couldn't load pickup availability
Guaranteed Safe Checkout
Description
FPGA Chip Model:ZNYQ7020-clg400, RF Chip Model: ad9361
Memory capacity: 512mb16bit, supporting gigabit network ports
Support for Zed+fmcomms2-3 routines Support for plutosdr routines
Supports dual reception and dual transmission, with better radio signal transmission performance compared to Plutosdr. FPGA resources are three times that of Plutosdr, and complex baseband algorithms are added. Equipped with a Gigabit Ethernet interface, the sampling bandwidth can reach
10mps(plutosdr5mps)
Supported upper computer sdr software such as matlab gnu radio sdrwin and adi official testing software have been ported to fmcoms2/fmcoms3
The software and HDL for hardware such as 2R2T, OpenWiFi, Pluto SDR, and ADRV9364 can connect with the official hardware tutorials and projects that require the above hardware.
Provide information: Plutosdr QSPI firmware source code, SD card firmware source code including (uboot device tree kernel), OpenWiFi source code, PDF schematic.
Features
Integrated dual core Cortex-A9 processor (766MHz), 85K logic unit
Frequency range 70M-6GHz, signal bandwidth 200K-56MHz
Rich interfaces for ETH, SD-CARD, USB-OTG, and USB-UART
Support ZED-FMCOMMS2-3/Open WIFI/Pluto SDR
Support for upper comp
Package include
1 x P210 SDR board
1 x 32G sd card
3 x Antenna
1 x SMA cable
1 x USB cable
1 x Network cable
