Mini Pocket Simple 2000 Counts Manual Range 10A 600V Resistance Students Use Teaching USE Digital Multimeter VC830L
Mini Pocket Simple 2000 Counts Manual Range 10A 600V Resistance Students Use Teaching USE Digital Multimeter VC830L
In stock
-
All orders are dispatched the next 3 business days!
-
We will beat any price. We back all products with a 1 year guarantee.
Order in the next 0 hours 0 minutes to get it by /12/2025
Couldn't load pickup availability
Guaranteed Safe Checkout
Mini Pocket Simple 2000 Counts Manual Range 10A 600V Resistance Students Use Teaching USE Digital Multimeter VC830L
Specification :
|
|
Range |
Basic accuracy |
|
DC Voltage |
200mV/2V/20V/200V/600V |
±(0.5%+4) |
|
AC Voltage |
200V/600V |
±(1.2%+10) |
|
DC Current |
200uA/2mA/20mA/200mA/10A |
±(1.5%+3) |
|
Resistance |
200Ω/2kΩ/20kΩ/200kΩ/20MΩ |
±(0.8%+5) |
|
Diode test |
√ |
|
Continuity buzzer |
√ |
|
Low battery indication |
√ |
|
Input impedance |
10MΩ |
|
Sampling rate |
3times/s |
|
AC frequency response |
(40-400)Hz |
|
Operation way |
Manual range |
|
Max. Display |
1999 |
|
LCD size |
57×33mm |
General Information:
|
Battery |
1x 9V(6F22) |
|
Product Net Weight |
Approx. : 150g |
|
Product Dimension |
138×72×35mm |
|
Standard Accessories |
Test leads / instruction manual |
Package List:
1pcs*Digital Multimeter(Not Included Battery)
