ToolkitRC MC8 Mini Size Cell Checker 32 Bit Battery Multi-Checker PWM Output PPM SBUS Readout with USB-C Fast Charging
Specification:
General
Product size: 68*50*15 mm
Product weight: 50g
Pack size: 76*60*30 mm
Pack weight: 100g
LCD: IPS 2.0inch LCD 320*240 Pixel
Checker
Main Input port: XT60 7.0-35.0V
Balance input: 0.5V-5.0V Lixx 2-8S
Signal port input: <6.0V
Balance current: MAX 60mA @2-8S
Balance accuracy: <0.005V @ 4.2V
USB-A output: 5.0V@1.0A firmware upgrade
USB-C output: 5.0V-12.0V @MAX 20W
USB-C protocol: PD3.0 QC3.0 AFC SCP FCP
Measurer
PWM: 880-2200us @20-400Hz
PPM: 880-2200us*8CH @20-50Hz
SBUS: 880-2200us*16CH @20-100Hz
Output
PWM: 1000-2000us @20-1000Hz
PPM: 880-2200us*8CH @20-50Hz
SBUS: 880-2200us*16CH @20-100Hz
Packaging included:
1X MC8 Charger
