Ca-888 12-18V LCD Universal Power Supply Board Module Switch Tube 300V for LCD Display TV Maintenance
Ca-888 12-18V LCD Universal Power Supply Board Module Switch Tube 300V for LCD Display TV Maintenance
In stock
-
All orders are dispatched the next 3 business days!
-
We will beat any price. We back all products with a 1 year guarantee.
Order in the next 0 hours 0 minutes to get it by /07/2026
Couldn't load pickup availability
Guaranteed Safe Checkout
Description:
Yellow : Drain (power control end, connected to pole D of the original high-power MOS power supply tube.
It is usually the middle leg of the power switch tube.
Black：GND (The ground wire of the module is 300V, connected to the negative terminal of the capacitor, and it can be directly connected to the negative terminal of the large filter capacitor on the same line.)
Red: VCC (power supply end of module, the positive pole of capacitor after rectified by feedback winding end, continuous power supply, voltage between 12V and 18V.)
White: FB (stable feedback, connected to the optocoupler 3 pins connected to the hot place, not the hot place to talk about the old optocoupler short to the hot place, and disconnect the 4 pins peripheral circuit)
Green: Start (starting pin, connected to the positive pole of 300V capacitor)
Description
Description
Description:
Yellow : Drain (power control end, connected to pole D of the original high-power MOS power supply tube.
It is usually the middle leg of the power switch tube.
Black：GND (The ground wire of the module is 300V, connected to the negative terminal of the capacitor, and it can be directly connected to the negative terminal of the large filter capacitor on the same line.)
Red: VCC (power supply end of module, the positive pole of capacitor after rectified by feedback winding end, continuous power supply, voltage between 12V and 18V.)
White: FB (stable feedback, connected to the optocoupler 3 pins connected to the hot place, not the hot place to talk about the old optocoupler short to the hot place, and disconnect the 4 pins peripheral circuit)
Green: Start (starting pin, connected to the positive pole of 300V capacitor)
