Assembled ATS20 SI4732 All Band Radio Receiver FM AM (MW & SW) SSB (LSB & USB) with lithium battery + Antenna + Speaker + Case

SI4732 All Band Radio Receiver FM AM (MW SW) SSB (LSB USB) Support Speaker with Antenna + USB Cable

Description:

Use 3.6V lithium battery
USB charging
Support audio output and 3.5mm headset
Support 8 ohm speaker 1W
FM output supports headphone antenna
Using BNC antenna interface
PCB retains si4735 package, users can change the chip by themselves, and the software is compatible.

Feature:
FM, am (MW and SW) and SSB (LSB and USB);
0.5, 1, 1.2, 2.2, 3 and 4kHz audio bandwidth filters
22 pre configured commercial radio and amateur bands
BFO control
Step frequency switch (1, 5 and 10kHz)

Frequency band

Fm_ band_ type,8400,10800,10430,10,
Lw_ band_ type,100,510,300,1,{Mw_ band_ type
520,1720,810,10,
Sw_ band_ Type, 172035001900, 1}, / / 160m
Sw_ band_ Type, 350045003700, 1}, / / 80m
Sw_ band_ type,
4500,5500,4850,5}
Sw_ band_ type,5500,6300,6000,5 },{Sw_ band_ type,
630078007050, 5}, / / 40m {SW}_ band_ type, 7800,10000,9600,5}
Sw_ band_ Type, 100001100010100, 1}, / / 30m
Sw_ band_ type,11000,12500,11940, 5},
Sw_ band_ type,12500,13900,13600,5 },{Sw_ band_ type,
13900, 14500, 14270, 1}, / / 20m
Sw_ band_ type,14500.15900.15300.5}
Sw_ band_ type,15900.17900, 17600,5}
Sw_ band_ type,17900,18300,?? 18100, 1}, / / 17m
Sw_ band_ type,18300,?? 2190021200, 1}, / / 15m
Sw_ band_ Type, 219002620024940, 1}, / / 12m
Sw_ band_ Type, 262002790027500, 1}, / / CB band (11m)
Sw_ band_ type,27900,30000,28400,1} //; // 10 meters

Package:

1 X Radio
1 X Antenna
1 X USB Cable
