80W-90W 400MHz-470MHz Interphone Car Radio UHF Ham Radio Power Amplifier
- Increase signal transmitting power and the power can reach 80W.The max power 100W.In the open,80W power with good antenna,the transmitting range can be 40-70km.
Parameter:
- Transmitting frequency:400-470MHz U section covering the whole period
- Output power:80W,use 13.8V 30A good linear power in 460MHz,it can output 90W,100W encroaching cattle
- Receiving loss:U segment 400-470 loss is superior to 1dB;V segment loss is superior to 0.7dB.
- The amplifier supports UV segment receive,the transmit only emission U section
- Receive current:When receiving,the amplifier does not consume any current;when transmitting,at the time of transmission power is automatically turned on,no need power switch.
- Input power:Suitable for all U section 2-7W hand power amplifier
- Power supply:12-14V,the voltage is standard vehicle voltage,the transmitting current 16A.Therefore,the power must be fierce,and we should buy 13.8V 30A or 50A.Linear power supply.Should be connected directly to the car using the car battery,cigarette lighter does not work.
Connection: The car radio connects amplifier input terminal golden SMA female head by a RF cable,the amplifier output port M female connects radio antenna bar.The power cable positive is red,the black is negative pole.
Package List:
- 1 x FM Radio Amplifier
Description
Description
80W-90W 400MHz-470MHz Interphone Car Radio UHF Ham Radio Power Amplifier
- Increase signal transmitting power and the power can reach 80W.The max power 100W.In the open,80W power with good antenna,the transmitting range can be 40-70km.
Parameter:
- Transmitting frequency:400-470MHz U section covering the whole period
- Output power:80W,use 13.8V 30A good linear power in 460MHz,it can output 90W,100W encroaching cattle
- Receiving loss:U segment 400-470 loss is superior to 1dB;V segment loss is superior to 0.7dB.
- The amplifier supports UV segment receive,the transmit only emission U section
- Receive current:When receiving,the amplifier does not consume any current;when transmitting,at the time of transmission power is automatically turned on,no need power switch.
- Input power:Suitable for all U section 2-7W hand power amplifier
- Power supply:12-14V,the voltage is standard vehicle voltage,the transmitting current 16A.Therefore,the power must be fierce,and we should buy 13.8V 30A or 50A.Linear power supply.Should be connected directly to the car using the car battery,cigarette lighter does not work.
Connection: The car radio connects amplifier input terminal golden SMA female head by a RF cable,the amplifier output port M female connects radio antenna bar.The power cable positive is red,the black is negative pole.
Package List:
- 1 x FM Radio Amplifier
