50M-6GHz Low Noise RF Amplifier Ultra Wideband Gain 20dB Medium Power Amplifier Board
Features:
-
50M-6GHz RF signal power amplifier with 20dB gain
-
Large dynamic range and wide operating frequency range
-
Suitable for all types of fixed gain amplification of RF signal
-
Wide frequency range, stable gain, small noise figure and large dynamic range (+ 20dBm @ 1dBP)
-
Suitable for all kinds of RF transmitting circuits to extend communications distance
-
Perfect for FM broadcast, remote control receivers, cable TV signal amplifiers
-
GPS satellite navigation, 2.4G Bluetooth, WIFI receiver RF end and other RF amplification
-
A shielded enclosure with anti-reverse protection diodes
Technical Parameters:
-
Operating Frequency: 50M-6GHz (50-6000MHz)
- Amplifier Gain: 20dB -
Max. Output Power: +21dBm(100mW)@1dB compression point
-
Working Current: 85mA (5V)
-
Power Supply Voltage: 5VDC【MicroUSB Power Supply】
-
System Impedance: 50Ω
-
Weight: 5g
Product List:
-
50M-6GHz Power Amplifier Board * 1
-
SMA connector cable *1
